Welding Tungsten Carbide Saw Tips For Cutting Aluminum Free Sample Available

ZHUZHOU SEEGO CARBIDE TOOLS CO., LTD.

Welding Tungsten Carbide Saw Tips For Cutting Aluminum Free Sample Available

Brand Name : Seego Carbide

Model Number : USA standard, Europe standard, JA, JX series

Certification : CE/ISO:9001

Place of Origin : China

MOQ : 1kg

Price : Negociated

Payment Terms : T/T, L/C, D/P, Western Union

Supply Ability : 5 tons per month

Delivery Time : 10-15 days

Packaging Details : paper packing+plastic box+carton

Material : Tungsten Carbide

Grade : K01-K05

Hardness : 92.3HRA

OEM : Accepted

Density : 14.86

Package : paper box outside

Sample : Free

Shape : Teeth Shape of Carbide Saw Tips

Series : Jx,Jp,Ja,Europen,USA

Work Piece : Wood, Metal

Contact Now

Welding Tungsten Carbide Saw Tips Used For Cutting Aluminum in Super Quality

Description of saw tips for saw blade

Tungsten carbide saw tips can process many kind of material,usually used for process wood materials. such as dry wood ,soft wood ,hard wood, original wood, solid wood, multiple wood, and nonferrous metal, most kinds of steel materials, granite, marble.

We are leading manufacturer for tungsten carbide saw tips in a wide sizes for wood, glass and metal, the normal size is JX3016 to JX16530, we can produce as customer's requirement.

Our company holds a massive experience in this domain and is involved in presenting an enormous quality range of Tungsten Carbide Saw Tips to our customers.

Features:

1. Easy to be welded

2. High hardness and wearability

3. Stable performance, no broken teeth

4. Perfect finish

5. Smooth installation

6. Accurate dimension

Type Dimension(mm)
L B C α° β° γ°
JX5316 5.3 1.6 4 30 20 0.5
JX5317 5.3 1.7 4.1 10 18 0.5
JX5417 5.4 1.7 4.1 20 20 0.5
JX5515 5.5 1.5 3.9 10 17 0.5
JX55155 5.5 1.55 4.3 28 15 0.5
JX5515A 5.5 1.5 4.3 28 - 0.5
JX5515B 5.5 1.5 5 30 0.48×45° 0.5
JX5516 5.5 1.6 4.3 28 15 0.5
JX5516A 5.5 1.6 3.9 30 14 0.5
JX5516B 5.5 1.6 3.9 20 14 0.5
JX5516C 5.5 1.6 4.3 28 15 0.5
JX5517 5.5 1.7 3.7 15 20 0.5
JX5517A 5.5 1.7 4.2 30 20 0.5
JX5517B 5.5 1.7 3.7 30 21 0.5
JX5517C 5.5 1.7 3.7 25 21.2 0.5
JX5518 5.5 1.8 3.7 30 24 0.5
JX5518A 5.5 1.8 3.9 25 25 0.5
JX5616B 5.6 1.6 4.3 30 0.5×45°
JX5618 5.6 1.8 3.3 24 - 0.5

Grade and application:

Grade Equal to ISO Category Number Performance useage
Density Bend Strength Hardness
G/Cm3 N/mm2 HRA
YG3 K01 14.9-15.3 ≥1180 ≥90.5 sand-blasting nozzlesQualified for fine turning and half-fine turning when cast iron, non-ferrous metal, alloys as well as non-alloy materials cutting consecutively. Can make wire drawing of steel and non-ferrous metal. Also qualified for sand-blasting nozzles.
YG3X K01 15.1-15.4 ≥1300 ≥91.5
YG6X K10 14.8-15.1 ≥1560 ≥91.0 Qualified for machining of chilled cast iron, alloy cast iron, refractory steel and alloy steel. Also Qualified for the machining of common cast iron.
YG6A K10 14.7-15.1 ≥1580 ≥91.0
YG6 K20 14.7-15.1 ≥1670 ≥89.5 Qualified for finish machining and semi-finish machining for the cast iron, non-ferrous metal, alloy and unalloyed materials. Also qualified for wire drawing for the steel and non-ferrous metal, electric drill for geology use and steel drill etc.
YG8 K20-K30 14.6-14.9 ≥1840 ≥89 Qualified for rough machining of cast iron, non-ferrous metal, nonmetal materials, drawing of steel, non-ferrous metal and pipes, various drills for geology use, tools for machine manufacture and wearing parts.
YT15 P10 11.1-11.6 ≥1180 ≥91.0 Qualified for rough machining, semi-finish machining and finish machining during consecutive machining of carbon steel and alloy steel.
YT14 P20 11.2-11.8 ≥1270 ≥90.5 Qualified for rough machining for rough face of carbon steel and alloy steel, half process during discontinuity cutting.
YT5 P30 12.5-13.2 ≥1430 ≥89.5 Qualified for rough machining for rough face of carbon steel and alloy steel and discontinuity cutting.
YW1 M10 12.7-13.5 ≥1180 ≥91.5 Qualified for finishing and semi-finishing machining of refractory steel, high manganese steel and common steel.
YW2 M20 12.5-13.2 ≥1350 ≥90.5 Qualified for semi-finishing machining of refractory steel, high manganese steel and common steel.

Permissible tolerance of cemented carbide saw tips:

Length Tolerance Width Tolerance Thickness Tolerance Radius Tolerance
Common Superior Common Superior Common Superior Common Superior
≤5 ±0.05 ±0.03 ≤2.0 +0.06
-0.04
+0.04
-0.02
≤1.5 ±0.05 ±0.03 ≤1.0 ±0.08 ±0.05
>5-7 ±0.08 ±0.05 >2-3.5 +0.08
-0.04
+0.04
-0.02
>1.5-2.5 ±0.06 ±0.03 >1.0-1.5 ±0.08 ±0.05
>7-9 ±0.12 ±0.05 >3.5-4.5 +0.08
-0.04
+0.06
-0.02
>2.5-4.0 ±0.06 ±0.04 >1.5 ±0.10 ±0.08
>9-12 ±0.15 ±0.07 >4.5-6.0 +0.08
-0.04
+0.06
-0.02
>4.0 ±0.07 ±0.04
>12 ±0.20 ±0.10 >6.0 +0.10
-0.05
+0.08
-0.02


Welding Tungsten Carbide Saw Tips For Cutting Aluminum Free Sample Available
